Wholesale Round Tubular Immersion Dishwasher Heater Rice Cooker Heating Element

YL-TYN016-4

minimum order

1 piece

Country of Origin

shanghai

Quantity:

$3.00 - $10.00 / piece

Contact Now

add to cart

After-sales Service Provided:Free spare parts
Warranty:3 years
Type:Electric Water Heater Parts
Application:Hotel
Power Source:Electric
Place of Origin:Jiangsu, China
Brand Name:YULING
Model Number:YL-TYN016-4
Product name:customized copper sickle hot water heater element
Experience:40 years heating element
Material:Copper
Voltage/wattage/Diameter:240V/1800W/8.5mm
Overall Lenth:260mm
Foldback Length:170mm
Screw thread:1"
Sample:For free
Warrant:1-5 years
Certification:CQC,CE,ROHS,ISO9001

Wholesale Round Tubular Immersion Dishwasher Heater Rice Cooker Heating Element

Our factory support design for the heaters.

we are good at making diameter size from 6.8mm-20mm.

Specification parameter	Detail	Remark
Sheath Material	Copper	Materialscan be changed to be copper,sus321,sus316L,incoloy804,incoloy800 as requested
Voltage/wattage	240v/1.8kw	Voltage/Wattage/Tolerance can be customized as required,and Wattage tolerance(cold condition)+5%-10%
Tube Diameter	8.5mm/0.33"	Tube diameter can be customized as required
Weight	310g
Screw thread	1"	Other thread can be made if required
MgO	A	We can use other powder if requested
Resistance wire	Ni80Cr20	Or OCr25Al5
Plastic shell	Nylon	Temperature resistance 160℃
Leads	Copper	Materials of terminal piece could be stainless iron,stainless steel if required
Faston Terminal	Nickel plated iron	Material of terminal housing could be stainless iron,stainless steel if required
Insulation resistance	≥1000MΩ(cold condition)
Leak current	≤0.5mA
Density	6.6W/CM2
Usage	electric water heater, brewery
Warranty	3-5 years

1,Our factory has more than 40 years' experiences of produce many kinds of heating elements;

2, We are a factory of Alibaba Assessed 4 years' Gold Supplier;

3, ISO9001,2008 listed, 100% QC inspection Before Shippment;

4, CE, CQC, RoHS UL listed!

5, Our products active in the market of Germany, Netherlands (philips),Australia, Switzerland, England, Cyprus, Canada, Brazil, Russia, France, Nigeria... Our products always got the praise from customers, whether price or quality.
